155M Single Fiber BIDI 1x9 Optical Transceiver
model： 5144-311-1PI?5146-211-1PI
The 19 transceiver supports 155Mbps and 80Km transmission distance with SMF. The transceiver consists of two sections: The transmitter section incorporates a DFB laser. the receiver section consists of a PIN photodiode integrated with a trans-impedance preamplifier (TIA).
Feature
l 1×9 package with SC connector
l 1310nm DFB Tx/1550nm PIN Rx and
l 1550nm DFB TX/1310nm PIN RX
l 80Km transmission with SMF
l +3.3V single power supply
l LVPECL compatible data input/output interface
l Low EMI and excellent ESD protection
l laser safety standard IEC-60825 compliant
l Compatible with RoHS
Application
l Ethernet
l Telecom
Mechanical Dimensions
.png)
Performance specifications
Absolute Maximum Ratings
Parameter Symbol Minimum Maximum Units Storage Temperature Tst -40 +85 °C Operating Temperature Top -40 +85 °C Supply Voltage Vcc 0 +3.3 V Input voltage Vin GND Vcc Lead Soldering Temperature & Time 240/10 °C/s
Operation Environment
Parameter Symbol Minimum Maximum Units Supply Voltage Vcc 3.15 3.45 V Ambient operating Temperature Top -40 +85 °C Operating Relative Humidity - 5 95 %
For detail, please check the datasheet in "Download".
